Bikeep IoT Platform

IoT Core

Dock controller activates lock, LEDs, alarms, detects end-switches, communicates with Contactless card reader and main controller.

Designed to be power optimal. Perhierias can be shut down (power cut off) to save power if the system is not active.

Lock manipulation

”Activated for locking” command or “Unlock” command

Activated for locking means that the controller is waiting for the lock end-switch status to be changed to a locked state

Lock status detection

Locked state, unlocked state

Alarm switch

The alarm is triggered if the switch is opened (Break Contact)

Cut wire

The alarm is triggered if the circuit is broken (Break Contact)

Piezo sound indication

Piezo sound is played for:

• Activated for locking
• Already locked denial sound
• Unlock

OTA update

Dock controller has a built-in bootloader, meaning that the dock firmware can be updated Over The Air

Bikeep readers can read public UID for most NFC/RFID cards with 13,56MHz.

Status (indication) LED shows the current state of the smart unit.
Also features blinking while locking activated or locking status changed.
8 segment RGB LED is used.

Available
Reserved
Unavailable / Under maintenance

Easy to install and maintain rotary lock delivers the convenience of electronic access control with the security of a proven, robust, all-metal rotary latch design in a compact, integrated package.
An integrated micro switches provides feedback on latch status, and re-lock option keeps a door unlocked for manual opening/closing cycles.
Lock has manual override option for mechanical opening.

General purpose Inputs/Outputs (GPIOs) Door detection
Session can Start/Stop only when contact is Closed or Open

Alarm switch
The alarm is triggered if the switch is opened (Break Contact)

Cut wire
The alarm is triggered if the circuit is broken (Break Contact)
